ESD Audit Kit – Accepts a Multitude of External Electrodes for Accuracy

Description

Perfect for testing to the newest esd resistance and field voltage standards. Test flooring, matting, wrist straps, smocks, personal charge generation, voltage decay, ion balance and more. Made in the U.S.A. Guaranteed best Pricing on the Web!



The RT-2000 by Static Solutions Inc is perfect for testing electrical resistivity and electrostatic field voltage output to the new ANSI ESD S20.20-2014 AND TR53 Standards. Reliable and accurately test esd flooring, esd floor finish, esd chairs, carts, esd smocks, ionizers, work surfaces, wrist straps, the resistance between technicians / heel straps / esd flooring and MORE!



The RT-20000 professional ESD Audit Kit includes many standard accessories and with readily available optional accessories this package can grow as industry standards (or your needs) change. The RT-2000 is designed to last a lifetime. It’s NIST certified, lightweight, versatile, and robust.



The RT-1000 resistivity megger is fully portable and measures resistivity and temperature / humidity (a prerequisite for reporting and saving the cost of purchasing an independent humidity / temp meter). Fully Ranging (from < 1.0E03 to 1.0E13) and 10 Volt or 100 V output capabilities. The RT-1000 Audit Kit accepts a multitude of external test electrodes for accuracy. Parallel bar electrodes are provided on the back of the RT-1000 spot checking matting etc.





The FM-1126 ESD Audit Kit

Use this ESD Audit Kit to locate the perfect placement for an ESD ionizer. Test the accumulated static charge on ANY insulative item including plastic, conveyer belts and even the technician’s clothing! This easy to use tool is invaluable for ALL ESD programs. The FM-1126 is compliant with ANSI ESD S20.20 and many other popular standards. The device includes an ion balance plate, grounding cable, soft shell case and NIST approved calibration documents. Made in the USA!



The RT-1000 ESD Audit Kit

• Easy to read digital display
• Measures electrical resistance from <1.0E03 to >1.0E12 ohms
• Measures relative humidity-10% to 90% RH
• Measures temperature: 32°F to 100°F (0°C to 37°C)
• 10v / 100v dual test voltage ranges
• Automatic zeroing and power off
• 9 Volt battery or 120V to 9 volt transformer (included with your order)
• Meets ANSI/EOS/ESD Standard 11.11
• CE Approved, NIST Traceable with Certificate included
• Options to EXPAND capabilities to garment, wrist straps, heel straps ETC…



The RT-1000 ESD Audit Kit

• Two 5lb. 2.5″ probes with handles
• Two 3″ parallel surface resistivity probes
• Dissipative chair test probe (meets ANSI/EOS/ ESD Standard 12.1)
• Garment clamps (conforms to EOS/ESD 2.1 standard))
• Earth ground probe
• Concentric ring probe available as an option
• Foam lined carrying case



The FF-1126 ESD Audit Kit

• Accurate measurements of static voltages.
• Accurate measurements of polarity.
• COMPLIANT to ANSI S20.20.
• RoHS compliant and free of conflict materials.
• Unique focus ring LED’s show proper measuring distance.
• Audible alarm protection if over range.
• NIST Compliant, includes certificate of compliance.
• Back lit technology, easy to read even in the dark!



Optional ESD Audit Kit Accessories / Replacement Items

• • CC-2641 Curly Cord Replacement Cables for RT-1000

$29.22 per pair

• • CC-2641 Straight Replacement Cables for RT-1000

$25.99

• • MP-6533 Personal hand held Electrode

$115.50

• • FP-1745 Personal Foot wear tester plate

$90.00

• • MP-1235 Miniature Probe

$307.99

• • RP-4323 2 ea 5 pound resistance electrodes

$138.50

• • GT-4872 Ground Circuit Tester

$27.50

• • GC-5621 Garment Clips

$71.50
