Static Control Flooring – Truly Resilient and Flexible but Durable!

Static Control Flooring features a case hardened top wear surface, is slip resistant, and is extremely easy to maintain for best results.

SKU: TITANIUM-ESD-TILE Categories: , ,

Description

< $4.93 PSF



2′ x 2′ tiles, Sheet Vinyl and Interlocking (no glue) ESD Floor Tiles. Elegant yet Powerful. Titanium like wear resistance, mission critical static control. Full surface static conductive backing for THE most complete charge decay in the industry.



ElectraFloor Titanium ESD Flooring features a case hardened top wear surface, is slip resistant, extremely easy to maintain and features ULTIMATE Static Control ESD Properties that Easily conform to the latest most stringent standards for static control. Titanium Tames the Static Beast BEFORE it Takes Another Byte.® Titanium is a pure vinyl devoid of cheap clay fillers and binders making it truly resilient and flexible (not brittle like many Static Control ESD flooring materials. Hence, Titanium may be flash coved up walls and handles heavy loading without breaking or delaminating.



Titanium features a Full Surface Static Conductive Backing allowing sheet floor installations simply unheard of in the past. ElectraFloor Titanium ESD Flooring may be installed over existing epoxy, VCT, limited porosity concrete, painted surfaces, sealed concrete and more using the URAS Adhesive Peel & Stick Method. Titanium sheet vinyl may also be installed in a permanent fashion using our Uzin KE 2000 liquid adhesive and heat welded for ultimate cleanliness. For installation of Titanium Static Control ESD Floor Tiles United recommends the use of Uzin KE 2000. Titanium’s perfect for a multitude of applications including server rooms, electronic assembly, munitions and pharmaceutical manufacturing.



Features
  • Full surface conductive backing. Ultimate Static Control ESD Flooring!
  • Case hardened. The most wear resistant vinyl in the Industry!
  • Truly resilient, won’t break, flake, crumble or degrade.
  • Produced in 4.5′ x 65′ sheet vinyl.
  • Produced in 2′ x 2′ ESD tiles (perfect for electronic assembly).
  • THE lowest maintenance flooring in the Industry!
  • Anti Slip! Added employee safety should the floor become wet!
  • Installation flexibility!  Sheet Vinyl may be installed over concrete, existing epoxy, VCT, even asbestos laden tiles (unlike other ESD flooring materials).



Why an ESD Sheet Vinyl?

Titanium Series Static Control ESD flooring is available in sheet goods (or optional tiles) for a very good reason. Let’s look at a 150′ x 60′ area. A typical 1′ x 1′ ESD tile will have over 18,000 linear feet (nearly 4 MILES of seams)! Take a look at this 3M ESD TILE floor.  Bad tiles? Poor install? Not at all. Unfortunately tiles don’t always fit perfectly and the installer must adjust (leave small spaces between the tiles) as the installation progresses (some tiles even shrink over a period of time).



And / or the substrate isn’t flat leaving an uneven profile (slight highs and lows) to the finished install.  Minute spaces between the tiles and  / or deviations in the flatness, a perfect environment for contaminant and dirt entrapment. On a standard tile floor these deviations typically present little problem, they are often filled in with floor wax. ESD floor finish shouldn’t be a necessity for a quality ESD floor.  It raises the insulative properties, can wreak havoc in a clean room (from powdering), is expensive and can be a maintenance application nightmare.



Why ESD Tiles?

Titanium Series Static Control ESD flooring is also available in a convenient 2′ x 2′ vinyl tile. ESD tiles are somewhat easier to install compared to sheet vinyl and with Titanium’s resilient vinyl properties the tiles can be flash coved up walls or more easily cut to tightly conform to columns and even server racks. PLUS tiles are easier to repair should they become stained, burned or torn! Titanium Tiles must be installed using our liquid conductive permanent adhesive. Tiles may not be installed using URAS Textile reinforced adhesive. Many clients choose to apply 2 thin coats of ElectraGlaze to their tile flooring to provide a protective layer that may be stripped when ground in dirt becomes problematic.
