ESD Carpet Tiles – Flawless LIFETIME Static Control Properties

Original price was: $307.43.Current price is: $261.32.

These ESD carpet tiles don’t require sprays, topical anti-stats or high humidity to achieve its lifetime static control properties.


$261.32 per SF carton

Color Options


ESD Carpet Tiles

ANSI ESD S20.20-2021 COMPLIANT, Lifetime Warranty

IN STOCK and ready to ship, 12 each 24″ x 24″  Carpet Tiles per carton, NO minimums, Made in the U.S.A!


UltraTech ESD Carpet Tiles provides flawless, LIFETIME Warranted Static Control properties in concert with outstanding wear performance and ease of maintenance. UltraTech II doesn’t require sprays, topical anti-stats or high humidity to achieve its lifetime fully warranted static control properties. UltraTech II is made in the U.S.A. and meets THE most stringent standards for Compliant ESD flooring. These carpet tiles interface flawlessly with drag chains, ESD carts, casters and chairs. They have a resistance level that makes them SAFE for use around energized equipment and are available in five popular designer colors. UltraTech may be installed over concrete or any existing well bonded hard surface floor (such as VCT).


UltraTech II is easily replaced should they get damaged, worn or stained as the conductive adhesive beneath the tiles stays permanently tacky. In addition, UltraTech’s outstanding sound deadening capabilities and cushioning can make your facility a comfortable working environment while it’s award winning designs highlight any facility as a show place of efficiency and technology. UltraTech II ESD Carpet Tiles are value oriented yet performance driven. Enjoy this premium carpeting at a price you will like, ergonomic comfort employees will love and conductivity that will let your ESD coordinators or MIS Department sleep well at night.


ESD Carpet Tiles Extended Information

Certified Installer Cut Sheet
Permanent / Releasable ESD Conductive Adhesive
Permanent / Releasable ESD Conductive Adhesive
Click Here for Samples of the Carpet Tiles


Physical Properties and Availability
Specification Value
Construction pattern loop, available in carpet tiles only.
Yarn Weight 22 oz per square yard
Total weight 22 oz per square yard
Stitches per inch >9.0 (31.49 / 10 cm)
Finished pile height .156″
Fiber Solution Dyed /yarn dyed 100% anti-stain nylon
Backing 100% PVC free recyclable
Flammability ASTM E-648 flooring radiant panel. Class 1 (>.45 W/cm2). ASTM E-6662 NBS smoke density <650
Sound Absorption ASTM C432-90; Noise Reduction Coefficient, NRC>.25
Size 24″ x 24″ (approx)
Packaging 12 tiles per carton (48.06 SF per carton)
Harmonized Tariff Code 7403190000


Note: This product has been awarded the Carpet and Rug Institutes’ Green Label Plus certification for indoor air quality. Green Label Plus is a voluntary testing program for carpet products that establishes the highest standards for indoor air quality that have ever been set by the carpet industry. Green Label Plus identifies carpeting that is tested by an independent, certified laboratory and meets stringent criteria for low chemical emissions.


Electrical Specifications
Specification Value
Electrostatic Propensity: ESD STM 97.2 (w/conductive footwear) <25 Volts (compliant is < 100 volts)
AATCC 134-06 (w/o conductive footwear) 0.4 kV (400 Volts)
Electrical Resistance: ESD S7.1 / NFPA 99 >2.5E04 <1.0E08
Electrical Performance: DOD HDBK263A, section 40.1.2 Meets recommended guidelines for sensitive ESD devices, Class 1
