Warning Labels & Warning Stickers – Call Attention to Hazards

These self adhesive warning labels call immediate attention to items that are susceptible to damage from static electricity.

Description

These bright yellow and black self adhesive esd awareness labels conform to MIL STD 129N, SYMBOL B627 and are designed to call immediate attention to items that are susceptible to damage from an electrostatic discharge (an esd event). We provide these in 4 sizes with a permanent adhesive backing. The labels are coated for added durability and resistance to water, moisture and many common chemicals. These labels further conform to the new ANSI ESD S20.20 requirements that ESD sensitive assemblies should be provided with a visible ESD susceptibility symbol.



Part Numbers

B6728: $16.69
B6728/5: $34.66
B6727: $13.22
B6725: $9.06



These bright yellow and black self-adhesive ESD warning labels conform to MIL STD 129N, SYMBOL B627 and are designed to call immediate attention to items that are susceptible to damage from an electrostatic discharge (an ESD event). We provide these in 4 sizes with a permanent adhesive backing. These warning labels are coated for added durability and resistance to water, moisture and many common chemicals. These labels further conform to ANSI ESD S20.20 requirements that ESD sensitive assemblies shall be provided with a visible ESD susceptibility symbol.



Per MIL STD 129N: 5.2.20.2 Intermediate and exterior containers. Intermediate and exterior containers shall be marked with the ESD sensitive devices attention label. The ESD sensitive devices symbol and the words “ATTENTION OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DISCHARGE SENSITIVE DEVICES” shall be marked in black on a yellow background. One 2- by 2-inch label shall be placed on the identification-marked side of an intermediate container. Two 4- by 4-inch labels shall be placed on each exterior container that exceeds one-half cubic foot. One warning label shall be placed on the identification-marked side (or surface), and one label shall be placed on the opposite side (or surface). Smaller exterior containers shall be marked in the same manner except that the 2- by 2-inch warning label may be used in lieu of the larger label. If the label is temporarily unavailable, intermediate and exterior containers shall be marked with the ESD sensitive devices symbol and the words “ATTENTION OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DISCHARGE SENSITIVE DEVICES”. The minimum size of the symbol shall be five-eighths of an inch measured vertically at the base of the triangle. When preprinted warning labels are not used, the symbol shall be printed in black or the same color as the identification markings, if other than black.



Warning Labels and Sticker Features
  • Clear and concise, outstanding visibility.
  • Each warning label marked for with MIL STD 129N, SYMBOL B627 for conformance!
  • Coated for resistance to grease, oils, water and many chemicals!
  • Fully compliant to latest ANSI ESD standards!
  • Lead free and RoHS compliant!
  • Perfect for marking static sensitive items in electronic manufacturing and other static sensitive environments!



Warning Labels and Sticker Specifications

MATERIAL: 60# semi gloss litho.
ADHESIVE: B-82
LINER: 40# R L.
WATER AND GREASE RESISTANCE: Excellent
WIDTH: 2″, 4″ and 5/8 inch.
LENGTH: 2″ or 4″
